CP203 – Pillow Block Bearing |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| ???? Main Dimensions |
|
|
|
|
|
|
|
|
|
| Bearing Number: UCP203 |
|
|
|
|
| Insert Bearing: UC203 |
|
|
|
|
| Housing Type: P203 |
|
|
|
|
| Shaft (Bore Diameter): 17 mm |
|
|
|
|
| Centre Height: ~30 mm |
|
|
|
|
| Base Length: ~127 mm |
|
|
|
|
| Bolt Size: M10 (approx.) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| ⚙️ Performance Specifications |
|
|
|
|
|
|
|
|
|
| Dynamic Load Rating (Cr): ~14.5 kN |
|
|
|
|
| Static Load Rating (Cor): ~7.95 kN |
|
|
|
|
| Fatigue Load Limit: ~0.32 kN (approx.) |
|
|
|
|
| Speed Limit (Grease): ~5,000 RPM |
|
|
|
|
| Speed Limit (Oil): ~6,000 RPM |
|
|
|
|
| Lubrication: Pre-greased (sealed type) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Features |
|
|
|
|
|
|
|
|
|
| Self-aligning insert bearing system |
|
|
|
|
| Strong cast iron housing body |
|
|
|
|
| Dust and dirt protection sealing |
|
|
|
|
| Smooth and low-friction rotation |
|
|
|
|
| Good vibration resistance |
|
|
|
|
| Easy installation and replacement |
|
|
|
|
| Long working life |
|
|
|
|
| Low maintenance requirement |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| ⚙️ Applications |
|
|
|
|
|
|
|
|
|
| Medium electric motor |
|
|
|
|
| Light conveyor system |
|
|
|
|
| Textile machinery |
|
|
|
|
| Fan blower system |
|
|
|
|
| Lathe machine support shaft |
|
|
|
|
| Light crusher machine |
|
|
|
|
| Agricultural machinery |
|
|
|
|
| Workshop machinery |
|
|
|
|
| Printing and packaging machine |
|
|
|
|
| General industrial use |
|
|
|
|
